Patch Cord
Patch Cord Features
- MeetsTelcordia GR-326 Core and ROHS
- Theconnector could be SC,FC,LC,ST,MU,E2000
- The cable could be G652D,G655,G657,OM1,OM2,OM3
- The cable size of simplex patch cord could be 9mm,1.6mm, 2.0mm,2.8mm
- The cable size of duplex patch cord could be 2×2.5mm, 1,6×3.3mm, 2.0×4.1mm,2.8×5.7mm etc.
Contact To Get Free Sample & Catalog
Privacy Policy: Security and Privacy Guaranteed 100%!
Patch Cord Description
Patch Cords are used to provide optical connection for fiber optic electronics. The use of the patch cord provides a quick and easy method for routing fiber patches in data centers, head-ends, cellular hubs and central offices. The patch cord can be used in interconnect or cross-connect path connecting the incoming fibers to the electronic equipment and providing patching within the fiber paths. Patch Cords include simplex, duplex and Multi-fibers assemblies.
Application:
- Fiber CATV
- Fiber Cabling system
- LAN & FTTH Network
Patch Cord Data Sheet
CONNECTOR | SC, FC, LC, ST, MU, E2000, MT-RJ(Duplex) |
POLISHING | SM/UPC     MM/PC     SM/APC     |
INSERTION LOSS(MAX) | ≤0.30dB     ≤0.25dB     ≤0.30dB     |
RETURN LOSS(MIN) | ≥50 dB     ≥35 dB     ≥60 dB     |
TENSILE STRENGTH | >70N (simplex); >60N (duplex) |
DURABILITY | <0.20 dB typical change, 1000 matings |
REPEATABILITY | ≤0.1dB |
STORAGE , OPERATING TEMPERATURE [°C] | -40~+85 |
